Welcome to BBRobots – Proof of Concept v0.5.0

This is a POC version of BBRobots, which means that this version implements some aspects that were not in the prototype. Indeed the previous version, being a prototype, was for presentation of the concept, and technical ideas to implement. Moreover, this version is now exposed as a configurable widget for any external site. Demo form →

This POC implements:

• The exposure as a widget (SaaS)
• The mechanics of the 3rd escalation (polygons challenge)
• The possibility to realize this challenge on mobile devices
• The mechanics allowing accessibility (code via SMS)
• The possibility to check on the back-end if the challenge has been completed by the user (and therefore a front-end blocking, and a back-end verification in case of bypass)

NEW: Behaviour analysis

• Check if the user was referred to the form page ot not
• Check the users lingering behaviour on inputs (time spend typing etc)
• Check the users scroll behaviour on the form page
• If the behaviour analysis concludes that no robot was detected, users should be able to submit without any challenge

Possible additional features

• validation via QR Code (2nd escalation) depending on behaviour score
• usage of API keys to better secure the access the captcha api
• more/other behaviour checks (mouse movement, time spend on the page, etc)
• lockout attemtps

How to integrate the BBRobots plugin

• Step 1
  • Insert this script in the form's page:
     <script src="https://bbrobots.technologypartner.io/dist/bbrobots-plugin.min.js"></script>
• Step 2
  • In order to know which form needs to be secured, you need to add this css class on the form itself:
     .bbr-challenge-trigger
  • To initialise the script you need to add this line in your main js file:
     window.bbrPlugin();

  • The plugin can take an optional options object as parameter to define custom colors.

    The default options are defined as such:

        {
            fillColor: 'skyblue', // color of the movable shape
            strokeColor: 'gray' // outline/border color of the other shapes
        }


    Pass in another color like the following for example:
     window.bbrPlugin({ fillColor: '#7fffd4' });

• Step 3

  On the backend of your server application, you should call the api to verify if the current session is allowed to post your form.

  Example C# implementation

      public static async Task<SessionState> CheckSession(string sessionId)
      {
          const string serverUrl = "https://bbrobots.technologypartner.io/api/session/verify";

          if (string.IsNullOrWhiteSpace(sessionId))
              return SessionState.MissingSessionId;

          HttpContent postContent = new StringContent(JsonConvert.SerializeObject(new { sessionId }), Encoding.UTF8, "application/json");

          var client = new HttpClient();
          var response = await client.PostAsync(serverUrl, postContent);
          if (response.StatusCode == HttpStatusCode.InternalServerError)
              return SessionState.HttpError;

          var result = JsonConvert.DeserializeObject<VerifySessionResult>(await response.Content.ReadAsStringAsync());
          return result.IsSessionValid
              ? SessionState.ValidSession
              : SessionState.InvalidSession;
      }


  Call the following API to execute the session verification:

  URL

  https://bbrobots.technologypartner.io/api/session/verify

  ---

  Method

  POST

  ---

  Payload

  Content-Type: application/json {sessionId: string}

  The current sessionId is stored inside a cookie named TP.BBRobots.SessionId.

  ---

  Result

  200 OKJSON

  {
      sessionId: string,     // current sessionId
      isSessionValid: bool,  // if the session is valid and if the form can be posted normally or not
      challenge: string      // name of the challenge if the session is not valid or 'Failed' when a robot was detected
  }


Demo

Go to demo form →
